Detrimental Effects of Collagen Crosslinking on Articular Cartilage Lubrication

Introduction:: Ex vivo studies suggest OA-associated cartilage softening may contribute to elevated shear and friction forces at the articular surface and predispose chondrocytes to acute cell death.^1-2 Thus, there has been great interest in using stiffening mechanisms, such as collagen crosslinking (CXL), to slow OA progression.^3-4 In classical stationary contact area (SCA) tests, OA-like cartilage slid at 1mm/s indeed experiences elevated friction coefficients (µ_k=0.25, vs. 0.15 in healthy tissue).⁵ However, similarly elevated µ_k values have been seen after CXL under identical testing conditions.⁴ Thus, the effects of cartilage stiffness on lubrication remain uncertain. Furthermore, the clinical relevance of SCA-based findings is unclear given that cartilage operates at higher average sliding speeds (30-80mm/s) and markedly lower friction (µ_k< 0.005) in vivo.⁶ Recent work leveraging the convergent stationary contact area (cSCA) reveals that sliding speeds >30mm/s facilitate interstitial fluid recovery and biofidelic µ_k (≤0.02 in saline and ≤0.005 in synovial fluid) via tribological rehydration. Critically, cSCA tribomechanical outcomes appear largely insensitive to of tissue stiffness in both healthy^6-7 and OA-like cartilage.⁸ Here, we examined whether CXL-mediated stiffening alters cartilage lubrication under biofidelic cSCA sliding.


Materials and Methods:: Osteochondral explants (Ø19mm) were extracted from mature bovine femoral condyles. A Ø4mm probe was used to indent each specimen in creep-relaxation (at 50µm/s to a 150mN load), and mechanical properties were determined by fitting the time-dependent normal force and indentation depth to Hertz biphasic theory.^8-9 Tribological testing comprised 30min static compression (7N) and 15min compression+sliding (80mm/s). Effects of CXL were examined in (i) healthy or (ii) OA-like cartilage (approximating ICRS grade 2; generated via chondroitinase-ABC (chABC) digestion).⁸ Explants were crosslinked with 10mM genipin (GP) in PBS for 24hr. Differences between groups were assessed via two-way ANOVA with Tukey’s post-hoc (significance at p< 0.05).


Results, Conclusions, and Discussions:: Results and Discussion: GP treatment of naïve cartilage increased E_y- from 0.53±0.20 to 0.87±0.27 (p< 0.001). There were no significant differences in tribological rehydration-mediated strain recovery after GP (p=0.30). Whereas naïve cartilage experienced near-physiological friction in PBS (µ_k=0.009±0.002), significantly elevated friction was observed after GP (µ_k=0.14±0.03; p< 0.0005). Next, we examined if synergy between tribological rehydration and synovial fluid (SF) lubrication could rescue the lubricity of GP-treated cartilage. Naïve cartilage sustained physiological (µ_k≤0.005) in SF-lubricated cSCA contacts, while GP-treatment led to elevated friction coefficients (µ_k=0.038±0.018; p< 0.005). Finally, we investigated the effects of GP treatment on the lubricity of OA-like cartilage generated via chABC-digestion. Digestion significantly decreased E_y- (p< 0.0005; Fig. 1A) but had no effect on strain recovery or friction coefficients (Fig. 1B-D). Subsequent GP treatment increased E_y- to 0.91±0.20MPa (p< 0.0005); Fig. 1A). These GP-treated tissues experienced significantly elevated friction coefficients of 0.13±0.06 and 0.032±0.017 in PBS- and SF-lubricated contacts, respectively (p< 0.005, Fig. 1C-D).



Conclusions: Here, we introduce the first biofidelic assessment of cartilage lubrication after genipin treatment, which has been proposed for “reinforcing” native and engineered cartilage.³ Despite persistent tribological rehydration, friction coefficients after GP exceeded those in paired naïve tests by 20- and 10-fold in PBS and SF, respectively. Exposure to such elevated friction coefficients should be extremely detrimental to chondrocytes, as multiple explant studies report marked cell death after just 30-60min of sliding at µ_k>0.05.^1,6 The high friction coefficients observed after GP treatment suggest collagen crosslinking is ill-suited for cartilage preservation. More importantly, this work demonstrates that biofidelic lubrication testing must be used to assess whether proposed OA treatments are suitable for the synovial joint microenvironment.




Acknowledgements (Optional): :

References (Optional): : ¹Bonnevie (2018) J Biomech. ²Bartell (2015), J Biomech. ³Santos (2022) OA&C Open. ⁴Oungoulian ⁵Bonnevie (2018) JOR. (2014) J Biomech ⁶Farnham (2021) CMBE. ⁷Kupratis (2022) Acta Biomater. ⁸Kupratis (2023) ORS. ⁹Moore (2016) J Tribol.
